Multus CNI กับ CDN Configuration — วิธีใช้

🌐 Network โดย อ.บอม กิตติทัศน์ เจริญพนาสิทธิ์ · เผยแพร่ 2026-05-28

Multus CNI

Multus CNI Meta CNI Plugin Kubernetes Pod หลาย Network Interfaces Secondary Networks Data Plane แยก Management Data Storage SR-IOV High Performance

CDN Content Delivery Network เซิร์ฟเวอร์กระจายทั่วโลก Cache เนื้อหาใกล้ผู้ใช้ ลด Latency Cloudflare CloudFront Fastly Akamai

Multus CNI Setup

# === Multus CNI Installation และ Configuration ===

# 1. ติดตั้ง Multus CNI
# kubectl apply -f https://raw.githubusercontent.com/k8snetworkplumbingwg/multus-cni/master/deployments/multus-daemonset-thick.yml

# 2. ตรวจสอบ
# kubectl get pods -n kube-system | grep multus
# kubectl get network-attachment-definitions

# 3. NetworkAttachmentDefinition — กำหนด Secondary Network
# apiVersion: k8s.cni.cncf.io/v1
# kind: NetworkAttachmentDefinition
# metadata:
#   name: data-network
# spec:
#   config: |
#     {
#       "cniVersion": "0.3.1",
#       "type": "macvlan",
#       "master": "eth1",
#       "mode": "bridge",
#       "ipam": {
#         "type": "host-local",
#         "subnet": "10.10.0.0/16",
#         "rangeStart": "10.10.1.20",
#         "rangeEnd": "10.10.3.250",
#         "routes": [{"dst": "0.0.0.0/0"}],
#         "gateway": "10.10.0.1"
#       }
#     }

# 4. SR-IOV Network (High Performance)
# apiVersion: k8s.cni.cncf.io/v1
# kind: NetworkAttachmentDefinition
# metadata:
#   name: sriov-net
#   annotations:
#     k8s.v1.cni.cncf.io/resourceName: intel.com/sriov_netdevice
# spec:
#   config: |
#     {
#       "cniVersion": "0.3.1",
#       "type": "sriov",
#       "vlan": 100,
#       "ipam": {
#         "type": "host-local",
#         "subnet": "10.20.0.0/24"
#       }
#     }

# 5. Pod with Multiple Networks
# apiVersion: v1
# kind: Pod
# metadata:
#   name: cdn-edge
#   annotations:
#     k8s.v1.cni.cncf.io/networks: data-network, sriov-net
# spec:
#   containers:
#   - name: edge-server
#     image: nginx:latest
#     ports:
#     - containerPort: 80
#     resources:
#       limits:
#         intel.com/sriov_netdevice: "1"

network_types = {
    "macvlan": {
        "description": "สร้าง Virtual NIC จาก Physical NIC",
        "performance": "ดี ใกล้เคียง Physical",
        "use_case": "ทั่วไป แยก Network",
    },
    "ipvlan": {
        "description": "คล้าย macvlan แต่ใช้ MAC เดียวกัน",
        "performance": "ดี",
        "use_case": "เมื่อ Switch จำกัด MAC Address",
    },
    "SR-IOV": {
        "description": "Hardware Virtualization ตรงจาก NIC",
        "performance": "ดีมาก ใกล้เคียง Bare Metal",
        "use_case": "High Performance, NFV, CDN Edge",
    },
    "bridge": {
        "description": "Linux Bridge เชื่อม Network",
        "performance": "ปานกลาง",
        "use_case": "ทดสอบ Development",
    },
}

print("Multus CNI Network Types:")
for net_type, info in network_types.items():
    print(f"\n  [{net_type}]")
    for key, value in info.items():
        print(f"    {key}: {value}")

CDN Configuration

# cdn_config.py — CDN Configuration
from dataclasses import dataclass, field
from typing import List, Dict

@dataclass
class CDNEdge:
    location: str
    ip: str
    capacity: str
    networks: List[str]

class CDNArchitecture:
    """CDN Architecture with Multus CNI"""

    def __init__(self):
        self.edges: List[CDNEdge] = []

    def add_edge(self, edge: CDNEdge):
        self.edges.append(edge)

    def show_topology(self):
        print(f"\n{'='*55}")
        print(f"CDN Edge Network Topology")
        print(f"{'='*55}")

        for edge in self.edges:
            print(f"\n  [{edge.location}] {edge.ip}")
            print(f"    Capacity: {edge.capacity}")
            print(f"    Networks: {', '.join(edge.networks)}")

    def cache_config(self):
        """CDN Cache Configuration"""
        cache_rules = {
            "Static Assets": {
                "pattern": "*.js, *.css, *.png, *.jpg, *.woff2",
                "ttl": "1 year (31536000s)",
                "cache_control": "public, max-age=31536000, immutable",
            },
            "HTML Pages": {
                "pattern": "*.html",
                "ttl": "5 minutes (300s)",
                "cache_control": "public, max-age=300, s-maxage=600",
            },
            "API Responses": {
                "pattern": "/api/*",
                "ttl": "0 (no cache) หรือ 60s",
                "cache_control": "private, no-cache หรือ max-age=60",
            },
            "Video/Audio": {
                "pattern": "*.mp4, *.webm, *.mp3",
                "ttl": "1 week (604800s)",
                "cache_control": "public, max-age=604800",
            },
        }

        print(f"\n  CDN Cache Rules:")
        for content, rule in cache_rules.items():
            print(f"\n    [{content}]")
            for key, value in rule.items():
                print(f"      {key}: {value}")

cdn = CDNArchitecture()

edges = [
    CDNEdge("Bangkok (TH)", "10.10.1.10", "100 Gbps",
            ["Management (eth0)", "Data (eth1-macvlan)", "Storage (eth2-sriov)"]),
    CDNEdge("Singapore (SG)", "10.10.2.10", "100 Gbps",
            ["Management (eth0)", "Data (eth1-macvlan)"]),
    CDNEdge("Tokyo (JP)", "10.10.3.10", "50 Gbps",
            ["Management (eth0)", "Data (eth1-macvlan)"]),
    CDNEdge("US West (US)", "10.10.4.10", "100 Gbps",
            ["Management (eth0)", "Data (eth1-sriov)"]),
]

for edge in edges:
    cdn.add_edge(edge)

cdn.show_topology()
cdn.cache_config()

# CDN Providers
providers = {
    "Cloudflare": {"type": "Global CDN + Security", "free_tier": "Yes", "edge_locations": "300+"},
    "AWS CloudFront": {"type": "AWS Integrated CDN", "free_tier": "1TB/month", "edge_locations": "450+"},
    "Fastly": {"type": "Edge Computing CDN", "free_tier": "Limited", "edge_locations": "80+"},
    "Akamai": {"type": "Enterprise CDN", "free_tier": "No", "edge_locations": "4000+"},
    "Bunny CDN": {"type": "Budget CDN", "free_tier": "Trial", "edge_locations": "120+"},
}

print(f"\n\nCDN Providers:")
for provider, info in providers.items():
    print(f"  {provider}: {info['type']} | Edges: {info['edge_locations']} | Free: {info['free_tier']}")

Nginx CDN Edge Config

# nginx_cdn.conf — Nginx CDN Edge Configuration

# # nginx.conf สำหรับ CDN Edge Server
# worker_processes auto;
# worker_rlimit_nofile 65535;
#
# events {
#     worker_connections 65535;
#     multi_accept on;
#     use epoll;
# }
#
# http {
#     # Performance
#     sendfile on;
#     tcp_nopush on;
#     tcp_nodelay on;
#     keepalive_timeout 65;
#     keepalive_requests 1000;
#
#     # Cache Path
#     proxy_cache_path /var/cache/nginx
#         levels=1:2
#         keys_zone=cdn_cache:100m
#         max_size=50g
#         inactive=7d
#         use_temp_path=off;
#
#     # Upstream Origin
#     upstream origin {
#         server origin.example.com:443;
#         keepalive 64;
#     }
#
#     server {
#         listen 80;
#         listen 443 ssl http2;
#         server_name cdn.example.com;
#
#         # SSL
#         ssl_certificate /etc/nginx/ssl/cert.pem;
#         ssl_certificate_key /etc/nginx/ssl/key.pem;
#         ssl_protocols TLSv1.2 TLSv1.3;
#
#         # Static Assets — Cache 1 Year
#         location ~* \.(js|css|png|jpg|jpeg|gif|ico|svg|woff2)$ {
#             proxy_pass https://origin;
#             proxy_cache cdn_cache;
#             proxy_cache_valid 200 365d;
#             proxy_cache_key $uri$is_args$args;
#             add_header X-Cache-Status $upstream_cache_status;
#             add_header Cache-Control "public, max-age=31536000, immutable";
#         }
#
#         # HTML — Cache 5 Minutes
#         location ~* \.html$ {
#             proxy_pass https://origin;
#             proxy_cache cdn_cache;
#             proxy_cache_valid 200 5m;
#             add_header X-Cache-Status $upstream_cache_status;
#         }
#
#         # API — No Cache
#         location /api/ {
#             proxy_pass https://origin;
#             proxy_cache off;
#             add_header Cache-Control "private, no-cache";
#         }
#
#         # Purge Cache
#         location /purge/ {
#             allow 10.0.0.0/8;
#             deny all;
#             proxy_cache_purge cdn_cache $uri;
#         }
#     }
# }

nginx_optimizations = {
    "sendfile": "ส่งไฟล์โดยตรงจาก Kernel ไม่ผ่าน User Space",
    "tcp_nopush": "ส่ง Headers และ Data พร้อมกัน",
    "keepalive": "ใช้ Connection ซ้ำ ลด Handshake",
    "proxy_cache": "Cache Response จาก Origin",
    "gzip": "บีบอัดข้อมูลก่อนส่ง",
    "http2": "Multiplexing หลาย Request บน Connection เดียว",
    "ssl_session_cache": "Cache SSL Session ลด Handshake",
}

print("Nginx CDN Optimizations:")
for opt, desc in nginx_optimizations.items():
    print(f"  {opt}: {desc}")

Best Practices

Multus: แยก Management Network กับ Data Network ชัดเจน
SR-IOV: ใช้ SR-IOV สำหรับ High Throughput CDN Edge Servers
CDN Cache: Static Assets cache นาน API cache สั้นหรือไม่ cache
Cache-Control: ใช้ immutable สำหรับ Versioned Assets
Purge: มี Cache Purge API สำหรับ Content Update
Monitoring: ติดตาม Cache Hit Ratio ควรมากกว่า 90%

Multus CNI คืออะไร

Meta CNI Plugin Kubernetes Pod หลาย Network Interfaces Secondary Networks แยก Management Data Storage SR-IOV High Performance NFV

CDN คืออะไร

Content Delivery Network เซิร์ฟเวอร์กระจายทั่วโลก Cache เนื้อหาใกล้ผู้ใช้ ลด Latency เพิ่มความเร็ว ป้องกัน DDoS Cloudflare CloudFront Fastly

ทำไมต้องใช้ Multus CNI

Pod ต้องการหลาย Network 5G Telco แยก Control User Plane Storage Network SR-IOV High Performance NFV หลาย Interfaces เหมือน VM

Multus CNI ใช้กับ CDN อย่างไร

แยก Network CDN Edge Management Network K8s Control Plane Data Network Content Delivery แยก Traffic ลด Congestion SR-IOV High Throughput

สรุป

Multus CNI Pod หลาย Network Interfaces macvlan ipvlan SR-IOV CDN Content Delivery Cache ใกล้ผู้ใช้ แยก Management Data Network Nginx Cache Configuration Cache-Control immutable Monitoring Cache Hit Ratio
